Thermashutter HS

THERMAshutter HS high-speed roller shutter doors

THERMAshutter HS

Image 1 of 3

Improve thermal efficiency and save on energy costs in the high-traffic areas of your industrial, commercial, warehousing and manufacturing facilities.

With their high thermal insulating properties and fast opening speed, the THERMAshutter HS insulated high-speed roller shutters substantially reduce energy costs.  Lightweight but robust, they provide high security against unauthorised access and theft, as well as the highest level of wind force resistance (up to 12 on the Beaufort scale).


Key Benefits

Reduce operational costs and save energy

Thanks to its high thermal insulation (R-value 1.63), the THERMAshutter HS insulated high-speed roller shutter maintains thermal integrity in temperatures ranging from +2°C to +95°C.

Maximise security

Lightweight but robust 20 mm thick aluminium slats make the THERMAshutter HS insulated high-speed roller shutter an economical alternative to conventional flexible curtain security doors.

The THERMAshutter HS resists even hurricane-level winds up to 137 km/h (up to 12 on Beaufort scale).

Reduce expenses associated with downtime and damaged doors

Lightweight aluminium slats resist corrosionand minimise stress on motor and components of the THERMAshutter HS insulated high-speed roller shutter.

In case if repairs become necessary, a small number of components makes them quick and cost-effective.

Ensure a high safety standard

Protect your personnel and reduce the risk of injury with the standard safety features of the THERMAshutter HS insulated high-speed roller shutter such as fall protection mechanism, light curtain and emergency chain operation.

Optional infra-red or radar motor sensors and warning/traffic lights can also be fitted.

Rely on German quality

Benefit from precise engineering, durability and reliability of EBS thermal efficient doors designed in Germany with electronics and motors made in Germany by GFA.


Technical Details



  • R-value: 1.63
  • Thickness of the thermal slats: 22 mm
  • Temperature range: +2°C to +95°C
  • Standard opening W x H: 4000 mm x 5000 mm
  • Maximum size W x H: 7000 mm x 6000 mm
  • Opening speed: up to 1.7 m/s
  • Wind load: up to 12 on the Beaufort scale (up to 137 km/h)
  • Standard colour: aluminium
